ISCOPE BINOCULARS AND TRINOCULARS

The series of microscopes iScope is designed with a focus on high-quality optics and extensive upgrade and enhancement options.

The metal body, thoughtful ergonomics, and reliable mechanical components ensure comfortable and convenient operation over extended periods. In addition to the classic bright field, users have access to optional configurations for phase contrast, dark field, polarization, and fluorescence.

The revolving nosepiece supports 5 objectives with anti-reflective and anti-fungal coatings, guaranteeing bright and clear images. Magnification ranges from 40× to 1000× by default, with the possibility of extending to 2000×. The lightweight aluminum body allows for easy movement of the microscope within the laboratory.

Models in the series are equipped with energy-efficient NeoLED lighting with a power of 3 W and adjustable intensity, making work even more convenient.

The combination of reliability, high quality, and economical energy consumption makes iScope microscopes an excellent choice for any scientific or clinical laboratory.

Specifications

✔ Parameter selection upon request
✔ Binocular/trinocular
✔ High-quality optics with anti-glare and anti-fungal coatings – this ensures long-lasting image quality
✔ Standard magnification 100x – 1000x with the possibility of extending to 40x-2000x times (optional)
✔ Wide-field EWF-plan phase eyepieces 10x/20 mm with diopter adjustment ± 5 diopters, suitable even for users wearing glasses
✔ Interpupillary distance adjustment: 48-76 mm
✔ Five-position revolving nosepiece for objectives with a ball-bearing mechanism
✔ E-plan EPL objectives: 4x/0.10; 10x/0.25; S40x/0.65; S100x/1.25 (oil immersion)
✔ Adjustable illumination: 3W, long-lasting NeoLED lamp, operates 20 times longer, without heating and consumes 10 times less energy (compared to halogen lamps)
✔ Focusing using macro and micro screws with a coaxial mechanism, division price 0.2 mm per rotation
✔ N.A. 1.25 Zeiss condenser with iris diaphragm and filter holder, as well as field diaphragm – create excellent image quality and contrast
✔ Methods: bright and dark field, phase and dark field contrast, simple polarization, fluorescence
✔ Stage 156 x 138 mm, with specimen holder and mechanical control along the X-Y axes in the range of - 79x52 mm
✔ iCare sensor: the microscope's illumination automatically turns off if the user steps away from the workstation, saving energy

MULTI-HEAD SYSTEM

iScope can be expanded with a unique multi-head system, allowing the use of two, three, or five heads, enabling simultaneous observation of samples. The central mount is equipped with a joystick for moving the green and red laser pointers across the entire field of view of all heads. Configurations with one, two, or four additional viewing binocular heads, inclined tubes at 30° and IOS plan objectives 4x, 10x, S40x, S100x with correction for infinity in oil immersion. All heads are equipped with extended plan EWF eyepieces 10x/22 mm
